3D Modeling
We took some pictures of the classroom. The first picture was the plan of the classroom.
1 Chair
The first object that we model was the chair. It had too many details. We started with the legs of the chair. To do that we learned how to do curve parts of the legs.
After
finishing the legs, we did the blue part.
We used bevel to make corners soft. And we added the texture that we got
from Photoshop.
Then, we
did the upper back side of the chair. We curled a cube, then we rotated it to
get as like as the original one.
After, we
spent a lot of time about these details, we got very similar chair with the
original one. For the bottom face of the chair, we used a texture too. Rest of
the details were handled by the polygons and we finished the chair. Then, we
copied the chair several times.
2 Cabinet
3 Board
To do the whole board, we first modeled one board by using the polygons. We did the curve part which is at bottom to put chalks. Then, we copied 3 times. So, we got 4 board. Then, we combined them like the original one.
We set the
color of board dark green.
4 Clock
For the clock, we first created polygonal pipe. Then, we added cylinder inside it. We used polygonal cube for the hour and minute hand and rest of the details. For the glasses we again used cylinders and we used mia_material_x and we get really good results when rendering with mental ray, however when we tried to export the clock to FBX format we get an error saying that mia_material_x is not supported and replaced with lambert grey. This was a big problem because we couldn’t import the clock correcly to the unity game engine. We had to change the material blinn and alter the options to get a glass-look, however we couldn’t make it as good as mia_material_x.
5 Ceiling
5.1 Ceiling
The ceiling of the classroom has so many details. We tried to do almost all of them. It has lights and a lot of sticks. We added long sticks according to the original one. We added lights as white.
5.2 Round Light
We modeled the lights on the ceiling with cylinders and polygon pipe. For this light we had the same problem as the clock because at first we used mia_material_x for the inner cylinder and we couldn’t export it to unity game engine appropriately. We had to switch to blinn material.
6 Hook
We model a hook according to the original one. We curved the cube to shape it. Then, we added half two half sapphire to the hook but we decreased the divisions so sapphires look like screws. We also add a screw image at the top of the screws.
7 Crown Molding
We tried to do crown Molding like in the pictures. The used curved cubes to do it but we did a small part of it because the length is not equal everywhere. After, we increased its length according to each wall and put.
1.8 Grid
There is a grid under the board. It was not very hard. We just added cubes and place it to the wall under the board.
9 Window
For the windows, we added 4 cubes to make the frame of one window. Then, we copied it several times to make the whole window. Then, we did the hinge of the window. We used cylinders for the hinge. For the glasses we again used cubes and we used mia_material_x and we get the same error while exporting to FBX format. We had to change the material blinn and alter the options to get a glass-look, however we couldn’t make it as good as mia_material_x.
10
Curtains
For the curtains we first used the CV curve tool and create a curve line then we created a long and thin cube and placed the curve line inside of it and add used Extrude under the Edit Mesh and increased the divisions so it bends according to the curve line. After creating the curved model we rescaled it.
11
Table
The table was not so hard. We model its legs first. Then, we added the upper side. For the edges, we used same texture that we used for chairs’ back side. For the middle of the table, we used the texture that we got from the picture of the original table.
12
Door
For the door we used a cube as bases and we used extrude tool to make 6 faces deeper. Then we used other thin cubes to cover around them. We used the door texture we made in Photoshop. For the glass part, we used blinn material as all of the other models with glasses. We first created the parts of the door knob in an additional scene and import it to the door and rescale it. We add the additional corners while putting the door to the room.
13
Classroom
Basically, we modeled the classroom like rectangular prism. However, there were some details that we cannot ignore. These were the details where near the windows and the door. There is a curve and hole near the windows. Also, there is a curve both side of the door.
To be able
to give the same level difference on the ceiling we created the room with
height equals to the heights part of the ceiling. After that we used a curved
cube to give the same curve and fill the rest of the ceiling.
Textures
We took photo of the chair, table, door and floor. Then, with the help of Photoshop we got textures. These are the textures that we used for the chair, table, door and floor.
Finally, we
used this texture for the table.
For the
rest of the objects we set the color and we tried to choose grey most of the
time like in the original picture.
Importing
into Unity
We saved all objects that we model as FBX files to use them in Unity. Then, we built a new project in Unity and added these FBX files. Then, we added a first person camera inside the room. Also, to make the objects more realistic, we added box collider component. We added skybox so that get a more realistic outside view from the window. Lastly, we added lights to some fluorescents because. We do not add lights to the round lights and some fluorescents because when we did that the class become bright and we did not like it. Then, we thought if we add light only some fluorescents, it can be look more realistic.
